FULLY AUTOMATIC ONLINE SHOPPING BOX TAPE APPLICATION MACHINE KS-1450

KS series automatic online shopping box tape applicator machine is an integrated solution for the global cross-border e-commerce carton to paste,folding gluing boxes,and form.At present,it is aimed at special-shaped 'zipper carton','cross-border mail box','post online shopping box' Obtained a large market share,and completely solved the problems of abnormal bending,it has obtained paper box out of order,product loss and other problems.The machine is simple and convenient to adjust,and can be ope

Friction Belt Feeder
This new design concept mainly focuses on irregular corrugated cartons. Horizontal feeding with the help of independent vibration motor completely solved the unsmooth feeding of irregular and bent boards.
Calibration Correction Device
Independent orientation, one side as the base to calibrate the box direction which makes the tape sticking precisely. The roller design make the transport more stable. The upper presser and under board can be adjusted according to the products' demand. This can keep the precision of sticking. Individual motor driving makes the machine running stably.
Tape Applicator
It is more humanity in adjusting and products changing. It is straight tracker in adjusting part. CSM self-developed 90 degree turning bracket is using on this machine. This technology decreases the dependability of the operators' technical. Even without any experience, the operators can run it easily with simple training.
Conveyor Section
The import 2mm thickness belt is soft enough for protecting products from pressing damage. Stack collection structure perfect the products quality. There is a products counting option.
Electrical Controller
Using the latest PLC cotroller system, equipped with European and Japanese international brand electrical control components, simple circuit control procedures, stable operation, low failture rate, convenient maintenance.

FULLY AUTOMATIC ONLINE SHOPPING BOX TAPE APPLICATION MACHINE Product Features:

FULLY AUTOMATIC ONLINE SHOPPING BOX TAPE APPLICATION MACHINE Product Parameters：

Model	KS-1450
Material	Over 300 g/㎡ cardboard, corrugated board
Min.open size	300mm×300mm
Max.open size	1450mm×1050mm
Working width	1050 mm
Max. Speed	90 m/min
Tape width	5-40mm
Power	3.2KW (380V AC 3φ 50Hz)
Weight	Approx. 1800KG
*Size LWH*	5700mm×2450mm×1200mm
